我使用以下代码来获取Kamada-Kawai布局:
template class PointMap
PointMap layout()const {
PointMap res;
boost :: associative_property_map PointMap temp(res);
minstd_rand gen;
rectangle_topology rect_top(gen,0,0,50,50);
random_graph_layout(g_,temp,rect_top); //随机布局以显示
// Kamada-Kawai不执行此任务
// circle_graph_layout(g_,temp,10.0);
// http://stackoverflow.com/q/33903879/2725810
// http://stackoverflow.com/a/8555715/2725810
typedef std :: map VertexDescriptor,std :: size_t IndexMap;
IndexMap mapIndex;
associationative_property_map IndexMap propmapIndex(mapIndex);
// http://www.boost.org/doc/libs/1_59_0/libs/graph/doc/bundles.html
kamada_kawai_spring_layout(
g_,temp,
boost :: make_transform_value_property_map([](int i)
- double {return i;},
get(edge_bundle,g_)),
// get(edge_bundle,g_) b $ b square_topology (50.0),side_length(50.0),
//layout_tolerance CostType (0.01),b
kamada_kawai_done(),
CostType(1),propmapIndex);
return res;
}
使用以下类型:
图表类型是:
boost :: adjacency_list vecS ,setS,undirectedS,State,CostType
其中 CostType 是 int 。
PointMap 是:
std :: map VertexDescriptor,square_topology :: point_type
这里是我使用的停止条件:
struct kamada_kawai_done
{
kamada_kawai_done():last_delta(){}
template typename Graph
bool operator()(double delta_p,
typename boost :: graph_traits Graph :: vertex_descriptor / * p * /,
const Graph / * g * /,
bool global)
{
if(global){
double diff = last_delta - delta_p;
if(diff 0)diff = -diff;
std :: cout \"delta_p:\" delta_p std :: endl;
last_delta = delta_p;
return diff 0.01;
} else {
return delta_p 0.01;
}
}
double last_delta;
};
请注意,在每次迭代中显示 delta_p 。
我运行这个只有一个简单的图形只有六个顶点。 delta_p 只显示一次,为0。由于初始布局是随机的,这真的很奇怪。这是我得到的图片:
如你所见,随机布局是\'
我尝试了另一个停止条件: layout_tolerance CostType (0.01)。
PS:因为我在这里做错了。无法在我的浏览器中看到图片,以防万一它没有附加,这里是图的邻接结构。该图表示对于三个煎饼的情况的煎饼拼图的状态空间。即,顶点对应于数字0,1,2的不同排列,并且来自每个顶点的两个边(所有权重为1):
[0,2,1]:
[2,0,1](w = 1)
[1,0,0](w = 1)
[ 2,0,1]:
[0,2,1](w = 1)
[1,0,2](w = 1)
[1,0,0] :
[0,2,1](w = 1)
[2,1,0](w = 1)
[2,1,0] 1,2,0](w = 1)
[0,1,2](w = 1)
[1,0,2]:
[2,0,1] (w = 1)
[0,1,2](w = 1)
[0,1,2]:
[1,0,2] b $ b [2,1,0](w = 1)
UPDATE :这里是我的代码实现接受的答案:
template class PointMap& PointMap layout()const {
PointMap res;
//将副本复制到更容易处理的图形中:
// - vecS用于顶点集,所以有索引映射
// - double边缘权重
使用LayoutGraph =
boost :: adjacency_list vecS,vecS,undirectedS,int,double
使用LayoutVertexDescriptor =
typename graph_traits LayoutGraph :: vertex_descriptor;
std :: map VertexDescriptor,LayoutVertexDescriptor myMap;
std :: map LayoutVertexDescriptor,VertexDescriptor myReverseMap;
LayoutGraph lg; //这是副本
//复制顶点
for(auto vd:vertexRange()){
auto lvd = add_vertex(lg);
myMap [vd] = lvd;
myReverseMap [lvd] = vd;
}
//复制边
for(auto from:vertexRange()){
for(auto to:adjacentVertexRange(from)){
auto lfrom = myMap [from],lto = myMap [to];
if(!edge(lfrom,lto,lg).second)
add_edge(lfrom,lto,(double)(g_ [edge(to,from,g _)。 b lg);
}
}
//使用LayoutPointMap =
完成复制
std :: map LayoutVertexDescriptor,square_topology :: point_type
LayoutPointMap intermediateResults;
boost :: associative_property_map LayoutPointMap temp(
intermediateResults);
minstd_rand gen;
rectangle_topology rect_top(gen,0,0,100,100);
random_graph_layout(lg,temp,rect_top);
// circle_graph_layout(lg,temp,10.0);
kamada_kawai_spring_layout(lg,temp,get(edge_bundle,lg),
square_topology(100.0),side_length(100.0),
//layout_tolerance CostType (0.01 ));
kamada_kawai_done());
for(auto el:intermediateResults)
res [myReverseMap [el.first]] = el.second;
return res;
}
对于6个顶点,布局是一个完美的性别,所以它工作!对于24个顶点,最后显示的 delta_p 为〜2.25(不应低于0.01?而且,当从随机布局开始比从圆形开始时布局更漂亮...
使用较小的矩形(例如20乘20而不是100乘100)导致不太漂亮的布局,并且使用 layout_tolerance double (0.01)作为停止条件。
解决方案
我认为中间近似可以存储在实际边束属性中,这使得它转换为整数。
由于输入的比例,它显然丢失了用于实现(局部)最佳布局的数字。我建议用双边的边缘束看看会发生什么。
